i-Player

Playout Solution (i-Player) is a solution built upon a client-server architecture that provides noticeable stability and usability advantages To allow an optimum CPU balancing in today's multi-core system, the server controls the video output while the client manages the playlist

Playout Solution (i-Player) provides fully automated or manually assisted playout of SD and HD channels, with user control from mouse, keyboard shortcuts control. SD/HD live sources and SD/HD video content in a range of codec formats can all be mixed for playout in the same playlist. Operators can cut and change the live playlist, even the event is currently on-air.

It commands a single architecture that can be easily grow to manage more than 1,000 channels. A powerful, configurable user interface maximizes efficiency, simplifies facility reconfiguration and enables to control large numbers of channels.

It is an automation system reflecting the needs of today and tomorrow. The no single point of failure redundancy of the architecture ensures ongoing stability, while the adaptability of our modular approach means that i-player is perfectly suited to bridge the switch to tomorrow’s multichannel content management and delivery environment.

Playout Solution system conveys trustworthy, frame-accurate control of multipart media distribution environments. It is an enterprise level automation solution designed to meet the demands of any high-capacity and dynamic broadcast Playout environment.

It supports the unique workflows associated with network content. With the ability to support regionalized marketable insertion, and advanced media workflows including conversion to any formats, enhanced redundancy, I-player is the preferred solution for network content providers. Pedestal on the start and end dates and account information you can create any schedule. I-Player enables you to group, sort or search any of the promotions. When the promotions have been scheduled then formed scheduled can be scrutinized and upgrade if the changes is required.

It is the ideal platform for active marketable environments due to its ability to support complex branding, maximize efficiencies in multichannel operations, and support rapidly changing schedules.

It offers integrated systems for mission-critical content management. When fully integrated with asset management solutions from i-soft Technologies for end-to-end broadcast monitoring and error-detection systems, the result is a high-quality, multichannel broadcast operation that is efficient and on-air continuously with a minimal amount of manual intervention.

Centralized Operations :

i-player supports several centralization strategies, including distributed, centralized and edge playout. i-player has the flexibility and feature set to accommodate any centralized practice.

Scalability :

i-player manages large statistics and a wide variety of channels, playout devices and material management services, operating efficiently with maximum operator yield. It can scale to over 1,000 distribution channels within single control architecture.

Unlimited Layering :

All running objects are assorted and unify to each other in coincident, including animations. The more CPU Power, the more objects can be layered simultaneously. This ensures an on tap amount of object combinations and extraordinary visual variety.

Security Providence :

All running air contents is maintained with Digital Signature, so it’s not relevant to make the revenue of the content by any circumstances. The media files are verified by the client application before being accepted for playout

Comprehensive Alarms :

i-player provides clear information about any alarm that is triggered, allowing you to work toward fast error resolution. All system errors are logged for later analysis. i-player offer brief information about any schedule or error or competence that is elicit, allowing you to keep straight toward the information of all activities.

Backup management :

Using automatic or manual synchronisation, multiple Player systems can run together for backup purposes, but synchronisation can be done either way between pairs of machines, or to multiple backup machines if required.

Cost Effectiveness :

When configured for dual idleness, backup computers (either local or remote) continuously outline the main so that they can take over instantly if necessary without any effect on running schedules.

Stream in multiple formats :

i- Player can play any type of file formats in any compression providing they all are in the same frame rate. Files supported include MXF, AVI, MOV and MPG.

Gapless Playout and switching – No black frames between videos and Live Switching.

Real-time monitoring with graphics on main windows.

DUAL AUDIO SELECTION

Schedule a single graphic with each event, and operators can use the position editor to determine where on screen it will be displayed.

Unlimited Metadata support for text- rich, and other formats.

Non restrictive editing of playlist during playback or streaming.

Video based logos and adv. Set different logo or scroll for different videos.

Very Fast trimming of certain video formats without any Transponder need.

Broadcast directly to the internet using windows media streaming.

Video content with different resolutions and bit rates and videos standards can coexist in the same playlist.

Video Clips triming and graphics design Preview.

Supports Multiple Media containers, as there are built in Transponder for many video, audio, image and other file formats.

The mode and recording parameters are set independently for every channels.

General mode to live switching mode with a real time instance.

Using 16.7 million colors and 256 transparency levels to fill any page element.

Automatic handling of time gap or overlaps in the playlist with default Fillers.

Semi Transparent scrolls with the transparency level up to 0-255 with content at the background.

Accurate Frame Based Spot Advertisement Ingestion as single, Group or Zone Basis Group of Spots.

High Quality Broadcast Graphics Overlay Templates for Breaking News, News Updates, Entertainment Graphics or Business Related Graphics.

Supports all basic and standard formats. HD, SDI, HDV, MPEG2, AVC/H.264, DIVx, VOB, DVD etc.

Ability to quickly change the video name before recording.

Redundant backup playout.

Export(manual and automatic) to/from XML

TV Schedule editing During the Playback.


PLAYER – EASE OF USE FEATURES:


Hotkeys – set up overlay or emergency events that apply to the whole playlist, or to groups or events within the playlist.

Group level scheduling – Overlays, hotkeys, and colour coding can be defined at group level (group and sub-groups) so there is no need to create individual effects for every event separately.

Search – there are a range of search features allowing operators to quickly find and correct schedules.

Cut, copy, and paste – use standard shortcuts to amend the schedule as with standard office packages. Operators do not have to enter items into, and correct schedules using a database and database forms.

Drag and drop from watched or windows folders – set folders to use for drag and drop scheduling operations.

Specifications and designs are subject to change without notice.

i-player applications are supported by major operating system.

The workstation should include:

  • Motherboard : GIGABYTE Z77 X D3H
  • Processor : INTEL CORE I7-3770 3.4
  • OS Hard disk : 120 GB SSD SATA Hard disk
  • Hard Disks : Western Digital 10,000 rpm (1 Hard disk per Channel)
  • WINDOWS OS : WINDOWS 7 Professional 64 Bit
  • RAM : 8 GB X 4 Slots - DDR3 Desktop
  • SMPS : 600 watts Cooler Master

Supported Outputs:

  • HD-SDI
  • SD-SDI
  • Composite/S-video/YUV
  • HDMI (SD,720p,1080i,1080p)/ PAL/ NTSC

Supported Inputs:

  • HD-SDI (Embedded Audio).
  • SD-SDI(Embedded Audio).
  • Composite/S-video/YUV(Auido balanced/unbalanced)
  • HDMI (SD,720p,1080i,1080p)

Aspect Ratio :

  • 16:9
  • 4:3

File Formats :

  • AVI,MKV.MOV,MXF,DV/DIF,VOB,MPG,TS
  • MPEG2,MP4

Graphics File :

  • BMP,TGA,GIF
  • PNG,JPG,TIF
  • SWF

Bitrates :

  • 1-15 Mbit/sec in MPEG-2
  • 25Mbit/Sec With HD
  • 1-8 Mbit in WMV
  • 64-320 Kbit/sec (Audio)

Hardware :

  • Works with Blackmagic's DeckLink or Intensity cards. The signals you can work with may be analog and/or digital depending of the card that is used.

Compatible With :

  • Windows XP, Windows 7, Windows 8, Windows 10...etc
